100Q36 Split Taper Bushed Sprocket

Product Details : 100Q36 Split Taper Bushed Sprocket

• Part No: 100Q36
• Product Type: ST (Split Taper)
• Bushing Type: Q1
• Chain Strand Type: Single
• ANSI Chain Size: 100
• No. Of Teeth: 36
• Pitch: 1-1/4"
• Pitch Diameter: 14.342"
• Outside Diameter: 15.040"
• Bore Max.: 2-11/16"
• Material(s): Carbon Steel
• Certifications: Manufactured using the ISO 9001 quality management system.
• Avg. Weight (lbs): 32

For any information about products, please contact us.

*Photos for reference purposes only.
