KBBC-24M | KB Chassis SCR DC Drive 1HP, 12/24 VDC (9500)

• KBBC Manual Available Here

• KBBC Data Sheet Available Here

Product Details : KBBC-24M | KB Chassis SCR DC Drive 1HP, 12/24 VDC (9500)

• Part No: 9500
• Product Type: KB Chassis SCR DC Drive
• Model No.: KBBC-24M
• HP: 1
• Input Voltage: 12/24 VDC
• Output Voltage: 12/24 VDC
• Output Amperage: 40
• Frequency (Hz): 50-60
• Enclosure NEMA: Chassis
• Enclosure IP: IP20
• Forward-Break-Reverse: Optional
• Features:
  • The KBBC-24M is a microprocessor controlled, DC-DC battery powered
  • Designed for 12 and 24vdc Permanent Magnet and Series Wound DC motors from 1/100 to *2HP*
  • Continuous rating of 40 amps and capable of peak currents of 80 amps for 7 seconds. *(2HP, 80amps DC)*
  • Contains many standard features such as:
  - current limit - short circuit protection
  - speed potentiometer fault detector
  - over-temperature sensing
  - under-voltage/over-voltage protection.
  • Eight trimpots are provided to tailor the low voltage DC-DC Drive to exact specifications.
  • Reversing contactors provide arcless forward, stop and reverse operation.
  • The controls contain a built-in heat sink that also serves as a mounting base
  • Dimensions: 4.10" x 6.30" x 1.70"

For any information about products, please contact us.

*Photos for reference purposes only.
