"L" Open End Timing Belt 12.7mm Wide - Steel Cord | LL050URSNFB

Product Details : "L" Open End Timing Belt 12.7mm Wide - Steel Cord | LL050URSNFB

• Part No: LL050URSNFB
• Product Type: Polyurethane Open End Timing Belt
• Length: Sold Per Foot (ft)
• Belt Profile: L
• Belt Pitch: 9.525mm
• Belt Width: 12.7mm (0.50")
• Tooth Height: 1.9mm
• Belt Thickness: 3.6mm
• Tooth Cover: None
• Back Cover: Nylon Fabric (Green)
• Max Traction Load (N) : 800
• Breaking Strength (N): 3215
• Elongation at MTL (mm/m) : 4
• Standard Width Tolerance: +/- 0.5mm
• Standard Length Tolerance: +/- 0.8mm
• Standard Thickness Tolerance: +/- 0.3mm
• ISO: ISO 5296-1
• Material(s): White Polyurethane Thermoplastic 92 ShA
• Material Cord: Zinked Steel (S and Z torsion)

Belts offered with AVAFC coating (60/70/85 ShA) and in custom widths. For more information and pricing about these custom products please contact us.

For any information about products, please contact us.

*Photos for reference purposes only.
