Leeson B313 | HVAC Motor 1/4HP, 1800RPM, 115/208-230V, Frame 48YZ, ODP
• Dimension Print Available Here
Product Details : Leeson B313 | HVAC Motor 1/4HP, 1800RPM, 115/208-230V, Frame 48YZ, ODP
- Part No: B313
- Product Type: HVAC Motor
- Category: Capacitor Start Induction Run
- Brand: Leeson/Marathon
- Frame: 48YZ
- Enclosure: ODP
- Horsepower (HP): 1/4
- Poles: 4
- RPM: 1400 to 1800
- Voltage: 115/208-230V
- Phase: 1
- Number Of Speeds: 1
- Frequency (Hz): 60
- Amps: 5.2/2.6
-
Features:
• Fan & Blower - Capacitor Start, Drip proof Motors
• Resilient Base Motors (Single & Two-Speed)
• Ball bearings, except as noted
• Heavy gauge steel frame and base
• Service factor, as noted
• Capacitor start / capacitor run as noted
• Thermal protection, as noted
• 48Y and 48YZ frame have 48/56 frame mounting holes
• UL recognized and CSA certified
• Model 048C17D2042
For any information about products, please contact us.
*Photos for reference purposes only.
Original: $220.40
-65%$220.40
$77.14
Description
• Dimension Print Available Here
Product Details : Leeson B313 | HVAC Motor 1/4HP, 1800RPM, 115/208-230V, Frame 48YZ, ODP
- Part No: B313
- Product Type: HVAC Motor
- Category: Capacitor Start Induction Run
- Brand: Leeson/Marathon
- Frame: 48YZ
- Enclosure: ODP
- Horsepower (HP): 1/4
- Poles: 4
- RPM: 1400 to 1800
- Voltage: 115/208-230V
- Phase: 1
- Number Of Speeds: 1
- Frequency (Hz): 60
- Amps: 5.2/2.6
-
Features:
• Fan & Blower - Capacitor Start, Drip proof Motors
• Resilient Base Motors (Single & Two-Speed)
• Ball bearings, except as noted
• Heavy gauge steel frame and base
• Service factor, as noted
• Capacitor start / capacitor run as noted
• Thermal protection, as noted
• 48Y and 48YZ frame have 48/56 frame mounting holes
• UL recognized and CSA certified
• Model 048C17D2042
For any information about products, please contact us.
*Photos for reference purposes only.
