Leeson G650 | Explosion Proof Motor Hazardous Duty 1/4 HP, 1200RPM, 115/208-230V, Frame 56 EPFC

• Dimension Print Available Here

Product Details : Leeson G650 | Explosion Proof Motor Hazardous Duty 1/4 HP, 1200RPM, 115/208-230V, Frame 56 EPFC

• Part No: G650
• Product Type: Explosion Proof Motor
• Category: Hazardous Duty
• Brand: Leeson/Marathon
• Frame: 56
• Enclosure: EPFC
• Horsepower (HP): 1/4
• Poles: 6
• RPM: 950 to 1200
• Voltage: 115/208-230V
• Phase: 1
• Number Of Speeds: 1
• Frequency (Hz): 60
• Amps: 6.8/3.4
• Features:
  • Hazardous Duty® Division 1 Explosion Proof Motors
  • Class I and II, Groups C, E (as noted), D, F & G
  • Steel frame, Single Phase motors
  • 1.0 Service factor
  • Automatic reset thermal protector
  • Economical split phase or capacitor start designs, as noted
  • Explosion proof conduit box included, shipped loose
  • UL listed file no. E12044
  • CSA certified file no. LR47504
  • Rigid base
  • Model 056C11G5306

For any information about products, please contact us.

*Photos for reference purposes only.
