Leeson X009 | HVAC Motor 3/4HP, 1200RPM, 115V, Frame 48Z, ODP

• Dimension Print Available Here

Product Details : Leeson X009 | HVAC Motor 3/4HP, 1200RPM, 115V, Frame 48Z, ODP

• Part No: X009
• Product Type: HVAC Motor
• Category: Permanent Split Capacitor
• Brand: Leeson/Marathon
• Frame: 48Z
• Enclosure: ODP
• Horsepower (HP): 3/4
• Poles: 6
• RPM: 950 to 1200
• Voltage: 115V
• Phase: 1
• Number Of Speeds: 3
• Frequency (Hz): 60
• Amps: 10.2
• Features:
  • Fan and Blower - Direct Drive, PSC Motors
  • Open Air Over, Resilient Ring, Thru-Bolt Mount Motors
  • Open frames and brackets (except X011 and X012) have enclosed shaft end bracket
  • Single and multi-speed models as noted
  • Grommeted lead exit
  • Weather resistant reversing plug
  • 2-1/4” resilient ring mounting except where noted (base not included, see accessories section)
  • 2 1/2” adapter rings supplied, shipped loose in box
  • Extended thru-bolts on shaft end
  • 30” long leads
  • Automatic reset thermal protector
  • Ball bearings
  • UL recognized and CSA certified
  • Capacitor not included, see accessories section
  • Model 048A11O787

For any information about products, please contact us.

*Photos for reference purposes only.
