Flanged Globe Valve Class 150 Stainless Steel 316

• Valve PDF

Product Details : Flanged Globe Valve Class 150 Stainless Steel 316

• Specifications:
  • Rising stem
  • O.S. & Yoke, Flexible Wedge
  • Body: ASTM A351 Gr. CF8M
  • Disc: ASTM A351 Gr. CF8M
  • Stem: SS316
  • Packing: PTFE
  • End Type: Flange end
  • Face to Face: ANSI B16.10
  • Flange Dimensions: ANSI B16.5 150 lbs
  • Wall thickness: ANSI B16.34
  • Test standard: API 598
• BONNET: ASTM A351 Gr.CF8M
• GLAND: ASTM A351 Gr. CF8
• HAND WHEEL: ASTM A536 Gr. B65, 45 & 12
• GASKET: PTFE (OR NON ASBESTOS)
• BONNET BOLT/NUT: ASTM A193 Gr. B8/ASTM A194 Gr. 8
• GLAND BOLT/NUT: ASTM A193 Gr. B8/ASTM A194 Gr. 8
• YOKE SLEEVE: BRONZE (OR DUCTILENI-RESIST)

For any information about products, please contact us.

*Photos for reference purposes only.
